Nginx的RTMP直播模块开发参数说明和配置范例
现在直播也是非常流行的一种应用场景,各种应用和H5页面上也经常用到直播。目前直播技术以RTMP方式是非常成熟的,虽然有10秒左右的延迟。但是这完全不影响直播的效果和稳定性。这次我们就以Nginx下的RTMP直播模块来讲一下直播的应用级别开发。安装这种类型的RTMP模块,需要重新编译NGINX服务。并且下载RTMP安装包。这里的安装和编译在另一篇牛人技术文章中说过了,在此就不多介绍了。下面我们来说说RTMP模块的一些命令参数和配置方法。
一. 直播RTMP模块中一些主要的配置选项
- rtmp
- server NGINX中的服务块
- listen 监听端口
- application 用于在NGINX配置文件中创建同一个程序块
- timeout 连接过期时间
- ping 测试数据包
- ping_timeout 测试数据包超时时间
- max_streams 最大流数量
- ack_window
- chunk_size
- max_queue
- max_message
- buflen
- out_queue
- out_cork
二. 在直播时的一些配置项
- live
- meta
- interleave
- wait_key
- wait_video
- publish_notify
- drop_idle_publisher
- sync
- play_restart
- idle_streams
三. HLS协议进行m3u8实时直播
- hls
- hls_path
- hls_fragment
- hls_playlist_length
- hls_sync
- hls_continuous
- hls_nested
- hls_base_url
- hls_cleanup
- hls_fragment_naming
- hls_fragment_naming_granularity
- hls_fragment_slicing
- hls_variant
- hls_type
- hls_keys
- hls_key_path
- hls_key_url
- hls_fragments_per_key
四. 录制直播视频以便回放重播
- record
- record_path
- record_suffix
- record_unique
- record_append
- record_lock
- record_max_size
- record_max_frames
- record_interval
- recorder
- record_notify
五;使用HTTP动态自适应不同带宽的视频
- dash
- dash_path
- dash_fragment
- dash_playlist_length
- dash_nested
- dash_cleanup
- MPEG-DASH
六. 用于视频点播的配置
- play
- play_temp_path
- play_local_path
七. 拉流转播到其他平台
- pull
- push
- push_reconnect
- session_relay
八. 直播状态的消息和状态
- on_connect
- on_play
- on_publish
- on_done
- on_play_done
- on_publish_done
- on_record_done
- on_update
- notify_update_timeout
- notify_update_strict
- notify_relay_redirect
- notify_method
九. 对直播的访问权限控制
- allow
- deny
- Exec 一簇函数(进程往往要调用一种exec函数以执行另一个程序)
- exec_push
- exec_pull
- exec
- exec_options
- exec_static
- exec_kill_signal
- respawn
- respawn_timeout
- exec_publish
- exec_play
- exec_play_done
- exec_publish_done
- exec_record_done
十. 其他RTMP的配置选项
- access_log 访问日志
- log_format
- max_connections 连接数Limits 限制
- rtmp_stat 数据统计
- rtmp_stat_stylesheet
- Multi-worker live streaming 多线程直播流
- rtmp_auto_push
- rtmp_auto_push_reconnect
- rtmp_socket_dir
- rtmp_control 直播Control 控制模块
十一. 下面是一个NGINX-RTMP直播配置的范
worker_processes 1;
events {
worker_connections 1024;
}
#这里开始是牛人技术测试直播的配置信息
rtmp {
server {
listen 1935;
chunk_size 4096;
application hls {
live on;
hls on;
hls_path /byDATA/NginxRtmpNRJS/webroot/tt/hls;
hls_fragment 5s;
}
#用来给115频道
application ANuid115 {
live on;
hls on;
hls_path /byDATA/NginxRtmp/webroot/ANuid115;
hls_fragment 5s;
}
#用来测试
application ANuid901 {
live on;
hls on; #实时回访
wait_key on; #保护TS切片
hls_nested on; #每个流都自动创建一个文件夹
hls_fragment 5s; #每个ts文件为5s的样子
hls_fragment_naming system;#使用系统时间戳命名ts文件
hls_playlist_length 10800s; #保存m3u8列表长度时间,默认是30秒,可考虑三小时10800秒
hls_cleanup on; #是否删除列表中已经没有的媒体块TS文件,默认是开启
hls_continuous on; #连续模式
hls_path /byDATA/NginxRtmp/webroot/live/record/ANuid901; #媒体块ts的位置
}
application ANuid902 {
live on;
hls on;
hls_path /byDATA/NginxRtmp/webroot/tt/ANuid902;
hls_fragment 5s;
}
application ANuid903 {
live on;
hls on;
hls_path /byDATA/NginxRtmp/webroot/tt/ANuid903;
hls_fragment 5s;
}
}
}
http {
include mime.types;
default_type application/octet-stream;
#access_log logs/access.log main;
sendfile on;
#tcp_nopush on;
#keepalive_timeout 0;
keepalive_timeout 65;
#byAdd
#include /byDATA/NginxRtmp/conf/*.conf; 此处可以添加自定义配置文件目录
#gzip on;
server {
listen 80;
server_name localhost;
#charset koi8-r;
#access_log logs/host.access.log main;
location / {
#byAdd
#root /byDATA/NginxRtmp/webroot/tt;
root html;
index index.html index.htm;
}
#error_page 404 /404.html;
# redirect server error pages to the static page /50x.html
#
error_page 500 502 503 504 /50x.html;
location = /50x.html {
root html;
}
# proxy the PHP scripts to Apache listening on 127.0.0.1:80
#
#location ~ \.php$ {
# proxy_pass http://127.0.0.1;
#}
# pass the PHP scripts to FastCGI server listening on 127.0.0.1:9000
#
#location ~ \.php$ {
# root html;
# fastcgi_pass 127.0.0.1:9000;
# fastcgi_index index.php;
# fastcgi_param SCRIPT_FILENAME /scripts$fastcgi_script_name;
# include fastcgi_params;
#}
# deny access to .htaccess files, if Apache's document root
# concurs with nginx's one
#
#location ~ /\.ht {
# deny all;
#}
}
#byAdd
server {
listen 80;
server_name flow.320023.com;
location /ANuid901 {
types {
application/vnd.apple.mpegurl m3u8;
video/mp2t ts;
}
root /byDATA/NginxRtmp/webroot/live/record;
add_header Cache-Control no-cache;
}
#推流状态查看 http://flow.320023.com/stat
location /stat {
rtmp_stat all;
rtmp_stat_stylesheet stat.xsl;
}
location /stat.xsl {
root /byDATA/NginxRtmp/Program/nginx-rtmp-module-master/;
}
#rewrite /ANuid901/(.*).m3u8$ /ANuid901/$1/index.m3u8 last; #重写用于兼容阿里云m3u8命名格式
#rewrite /ANuid901/(.*).ts$ /ANuid901/StreamName/$1.ts last; #重写让上面m3u8能找到ts文件
}
# another virtual host using mix of IP-, name-, and port-based configuration
#
#server {
# listen 8000;
# listen somename:8080;
# server_name somename alias another.alias;
# location / {
# root html;
# index index.html index.htm;
# }
#}
# HTTPS server
#
#server {
# listen 443 ssl;
# server_name localhost;
# ssl_certificate cert.pem;
# ssl_certificate_key cert.key;
# ssl_session_cache shared:SSL:1m;
# ssl_session_timeout 5m;
# ssl_ciphers HIGH:!aNULL:!MD5;
# ssl_prefer_server_ciphers on;
# location / {
# root html;
# index index.html index.htm;
# }
#}
}
RTMP直播配置总结
总体来说NGINX进行直播服务的配置,和编译不算特别难。只是在编译环境和配置选项上有需要注意点
